Lindy 350m Fibre Optic USB 3.0 Extender

Descriere

Extender USB 3.0 thru Fibre Optic, 350m

Extender USB 3.0 thru Fibre Optic, 350m
350m USB 3.0 Extension via fibre optic cabling

Description

• Extends USB 3.0 connections up to 350m
• Supports data transfer rates up to 5Gbps
• Uses standard “off the shelf” LC duplex fibre cabling
• Resistant to RF & EM Interference for use in highly sensitive areas

Technical details

Specifications

• USB Standard: USB 3.1 Gen 1 / USB 3.0
• Supported Bandwidth: 5Gbps
• Maximum Distance: 350m (1148.28ft)
• Transmission Medium:
  • 100m (328.08ft) – 1 x Multimode 62.5µm/125µm OM1
  • 200m (656.16ft) – 1 x Multimode 50µm/125µm OM2
  • 350m (1148.28ft) – 1 x Multimode 50µm/125µm OM3

• Chipset: TI TUSB8041 and Macom
• Special Features: –



Connectors

• Transmitter Input: USB Micro-B (Female)
• Transmitter Output: Duplex LC (Female)
• Receiver Input: Duplex LC (Female)
• Receiver Output: USB Type-A (Female)
• Power: 5.5/2.1mm DC socket



Physical Properties

• Dimensions WxDxH: 57x93x28mm (2.24×3.66×1.1in)
• Housing Material: Metal
• Net Weight:
  • Transmitter: 0.125kg (0.28lb)
  • Receiver: 0.129kg (0.28lb)
• Operating Temperature: 0° – 50°C (32°F – 122°F)
• Storage Temperature: -20°C – 70°C (-4°F – 158°F)
• Humidity: 20 – 80% RH (non-condensing)
• Power Requirements: 5VDC 3A
• Colour: Black



Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 154x123x115mm (6.06×4.84×4.53in)
• Gross Weight: 0.643kg (1.42lb)
• Warranty (Years): 2
• Certificated: CE, FCC, REACH, ROHS, California Proposition 65



Package Contents

• 1 x Transmitter
• 1 x Receiver
• 1 x Multi-Country PSU DC 5V 3A (EU/UK/US/AUS)
• Lindy Manual
